Single-link DVI cable
Carries the digital-video channel in a 24 AWG high-speed construction with controlled pair-to-pair and intra-pair skew.
/
DATA / DVI / 07
DVI Digital Video Cables
24 AWG single-link digital-video interconnect for aerospace and defense displays, controlling its 100-ohm differential channel, insertion loss, pair-to-pair skew and intra-pair skew from −65 to +200 °C in demanding EMI environments.
100 ± 10 Ω−65 to +200 °C24 AWG
PRODUCT FAMILYData Cables ↗
01 / CONFIGURATION DIRECTIONS
Select a configuration from the application boundaries
These configurations establish a practical discussion starting point. The final product requires a controlled specification based on interface, length, installation and validation conditions.
Circular-connector assembly
Integrates video pairs, auxiliary conductors and shield continuity into airborne circular-connector termination.
Display-system harness
Defined around resolution, channel length, routing and platform EMI conditions.
Match a solution direction to the link target
Solution codes support early technical discussions by aligning protocol, construction, link boundaries and application in one view.
SOLUTION CODEPROTOCOL / RATECONSTRUCTIONKEY BOUNDARYBEST FIT
CM-DVI-SL-24Single-link DVI24 AWG high-speed pairs plus auxiliary wires and composite shield100 ± 10 Ω · pair-to-pair skew ≤ 52.50 ps/mCockpit displays, mission workstations and digital mapping
CM-DVI-CIRCCircular-interface DVI assemblyControlled-impedance cable with airborne circular termination−65 to +200 °C · < 15 VAirborne equipment, vehicle displays and serviceable harnesses
CM-DVI-HARNESSCustom digital-display channelDefined by length, shield grounding and equipment interfacesIntra-pair skew ≤ 13.12 ps/m · channel validationCustom displays, image processing and high-EMI platforms
MODEL NOTESolution codes support early interface, length and installation matching. Final part number, conductor definition, connector pinout, shield termination and complete-channel performance are confirmed in the drawing and technical specification.
02 / PERFORMANCE PARAMETERS
Product performance parameters
The following values describe current product performance boundaries, with the applicable model, construction or test condition retained.
PERFORMANCE METRICVALUECONFIGURATION / CONDITION
01Standard impedance100 ± 10 Ω
Differential channel
02Typical operating voltage< 15 V
Digital-video system
03Velocity / delay80% · 4.07 ns/m
Nominal values
04Capacitance40.0 pF/m
Nominal value
05Pair-to-pair / intra-pair skew52.50 / 13.12 ps/m
Maximum values
06Dielectric withstand1500 / 1000 Vrms
Conductor-conductor / conductor-shield
07Temperature range−65 to +200 °C
Engineered-fluoropolymer jacket
Values apply to the 24 AWG single-link digital-video construction.
Technical referenceValues are confirmed against category, gauge, length and termination
03 / TYPICAL CONSTRUCTION
From functional core to terminated interface
Silver-plated copper-alloy conductors
Gauge, voltage drop, strength and termination contacts define the conductor construction.
Low-loss insulation
Expanded PTFE/PTFE controls impedance, delay and high-frequency attenuation.
Controlled signal units
Differential pairs, quads or multichannel video/data units are formed around the protocol.
Individual and overall shields
Pair coupling, external EMI and connector return continuity are managed together.
Environmental jacket
Wide temperature, abrasion, flame, marking and harness termination are balanced.
04 / SELECTION & VALIDATION
Inputs needed to start a custom assessment
SELECTION ITEMINFORMATION TO CONFIRM
01Protocol and speed
Interface revision, target rate, encoding and maximum channel length
02Electrical boundary
Impedance, insertion/return loss, skew and dielectric withstand
03Channel construction
Pair count, auxiliary wires, power and shield zoning
04Installation envelope
Gauge, diameter, mass, bend radius and harness section
05Environment
Temperature, vibration, abrasion, fluids, smoke/toxicity and flame
06Termination
Connector, contact, backshell, grounding and strain relief
Typical applications
- Cockpit and vehicle displays
- Mission systems and workstations
- Flight management and weather mapping
- In-flight entertainment
Interfaces & delivery
- Aerospace circular or rectangular connectors
- High-density contacts and backshells
- Pigtail, fixed-length harness or complete assembly
ENGINEERING NOTE
Data rate and channel capability depend on the final cable, length, connectors and termination process and must be confirmed as a complete channel.
Ready to define a controlled specification?
Bring us the interface, environment and validation requirements.
Yidong Telecom can build a sample direction and validation matrix around the cable construction, termination and system boundaries.
Submit requirement checklist ↗
